Teledyne LeCroy HVD3106A-NOACC: 1 kV, 120 MHz Differential Probe with Auto Zero

Features and Specifications: Teledyne LeCroy HVD3106A-NOACC Differential Probe, 1 kV, 120MHz, Auto Zero, No Acc, HVD3000A Series

Product Overview:

The Teledyne LeCroy HVD3106A-NOACC is a high-voltage differential probe designed for accurate and reliable measurements in high-power electronics applications. With its 1 kV differential input range and 120 MHz bandwidth, it provides exceptional performance for capturing fast transients and high-frequency signals.

Features:

Differential input range: ±1 kV
Bandwidth: 120 MHz
Auto Zero function for accurate offset compensation
No Acc (no accessories) configuration for maximum flexibility
Compatible with HVD3000A Series probes

Input impedance: 10 MΩ || 10 pF
Common mode rejection ratio (CMRR): >100 dB at DC, >60 dB at 120 MHz
Maximum input voltage: ±1 kV
Bandwidth: DC to 120 MHz (-3 dB)
Rise time: <3 ns
Input capacitance: 10 pF
Output impedance: 50 Ω
Power supply: Probe power supply (HVD3000A Series)

HVD3106A-NOACC Differential Probe
Ground lead
User manual

Benefits:

High-voltage measurements: Accurately measure high-voltage signals up to ±1 kV.
Wide bandwidth: Capture fast transients and high-frequency signals with a bandwidth of 120 MHz.
Auto Zero: Ensure accurate measurements by automatically compensating for offset errors.
No Acc configuration: Customize the probe setup by using your own accessories.
* Compatibility: Seamlessly integrate with HVD3000A Series probes for a complete high-voltage measurement solution.

Value to the Customer:

The Teledyne LeCroy HVD3106A-NOACC Differential Probe empowers engineers and technicians with the ability to perform precise and reliable high-voltage measurements. Its exceptional performance and flexibility make it an indispensable tool for power electronics design, testing, and troubleshooting.
