Features
-
- Single-hand operation with right- and left-hand viewing flexibility
- Large, easy-to-read digital display
- Enhanced wear life with carbide-faced contacts – available from 1/2 to 8
- Convenient Go/No Go tolerance indicator lights
- True alignment with mechanically-driven parallel anvils
- Push button inch/metric conversion
- Preset and preset recall
- Hold, max/min and zeroing capabilities
- Blind bore measurement is standard from .50 (12.7mm) and above
- Output capability for Statistical Process Control (SPC) analysis
>
>
Specifications
- Range (in): 4.00-6.00
- Range (mm): 100-150mm
- Resolution (in): .00005
- Resolution (mm): 0.001mm
- SPC Output: SPC Output
- Approximate Measuring Depth (in): 4
- Approximate Measuring Depth (mm): 100mm
- Number of Heads: 2
- Number of Rings: 1
