Megger CHM600

The Megger CHM600 Cable Height Meter utilizes ultrasonic sound to determine the height of up to six overhead cables and wires. The instrument is designed to address specific measuring requirements on cables up to 50 feet. The CHM600 is designed primarily for power cable applications.

• Measures the height of up to six overhead cables without touching or connecting to the wires
• Built-in temperature sensor improves measurement accuracy by accounting for variations in the speed that sound travels in different ambient temperatures
• Provides readings in meters, feet, or inches
• Calibration feature helps ensure accuracy of readings
• Automatically turns off after three minutes of non-use to conserve battery life

>

Each Unit Includes

• Megger cable height meter
• (1) 9V battery (installed)
• Instructions
