Anritsu S820E/0708 Antenna Analyzer: Precision Testing from 1 MHz to 8 GHz

Features and Specifications

Anritsu S820E/0708 Antenna Analyzer w/ 3-Yr Warranty, 1 MHz – 8 GHz, Type-N(f) Ports, Site Master Series

Features:

Frequency range: 1 MHz to 8 GHz
Type-N(f) ports
120 dB dynamic range
0.01 dB resolution
100 kHz to 3 MHz sweep speed
Built-in VSWR, return loss, and impedance measurements
Distance-to-fault (DTF) measurements
Cable loss and gain measurements
Smith chart and polar plot displays
USB and Ethernet connectivity

Specifications:

Frequency range: 1 MHz to 8 GHz
Power range: -70 dBm to +20 dBm
VSWR range: 1:1 to 100:1
Return loss range: 0 dB to 60 dB
Impedance range: 0 to 1000 ohms
Distance-to-fault range: 0 to 1000 meters
Cable loss range: 0 dB to 100 dB
Cable gain range: 0 dB to 60 dB

Product Overview

The Anritsu S820E/0708 Antenna Analyzer is a high-performance instrument designed for testing and troubleshooting antennas and other RF devices. It offers a wide frequency range, high dynamic range, and excellent resolution, making it ideal for a variety of applications, including:

Antenna testing
Cable and waveguide testing
Filter testing
Amplifier testing
Impedance matching

Anritsu S820E/0708 Antenna Analyzer
Type-N(f) to Type-N(f) adapter
USB cable
Ethernet cable
Power cord
Quick start guide

Accurate and reliable measurements: The S820E/0708 provides accurate and reliable measurements of VSWR, return loss, impedance, distance-to-fault, cable loss, and cable gain.
Wide frequency range: The S820E/0708 covers a wide frequency range from 1 MHz to 8 GHz, making it suitable for testing a variety of antennas and RF devices.
High dynamic range: The S820E/0708 offers a high dynamic range of 120 dB, allowing it to measure signals with a wide range of power levels.
Excellent resolution: The S820E/0708 has a resolution of 0.01 dB, providing detailed and accurate measurements.
Fast sweep speed: The S820E/0708 offers a fast sweep speed of 100 kHz to 3 MHz, allowing for quick and efficient testing.
Built-in measurements: The S820E/0708 includes a variety of built-in measurements, including VSWR, return loss, impedance, distance-to-fault, cable loss, and cable gain.
Easy-to-use interface: The S820E/0708 features an easy-to-use interface with a large color display and intuitive menus.
* Rugged and portable: The S820E/0708 is rugged and portable, making it ideal for field testing.

Value

The Anritsu S820E/0708 Antenna Analyzer is a valuable tool for anyone who needs to test and troubleshoot antennas and other RF devices. It offers a wide range of features and benefits, including accurate and reliable measurements, a wide frequency range, a high dynamic range, excellent resolution, a fast sweep speed, built-in measurements, an easy-to-use interface, and a rugged and portable design.
